Bluegiga Classic Module Common Specs
Bluetooth:
- Bluetooth 4.1 Smart Ready compliant
- Up to 6 x BR/EDR connections
- Up to 7 x BLE connections1 x BR/EDR + 7 x BLE connections simultaneously
- SPP, iAP2, HID and GATT over BR Bluetooth profiles
- Any Bluetooth Smart profile
- 1000 kbps throughput over SPP
- 200 kbps throughput over iAP2
- 100 kbps throughput over BLE
Hardware Features:
- UART host interface
- SPI, UART and I2C peripheral interfaces
- GPIO and ADC
- RTC
- Supply voltage: 2.2 V to 3.6 V
- Dimensions: 11.0 mm x 13.9 mm x 2.2 mm
Radio:
- Integrated antenna
- TX Power: +12 dBm with Bluetooth BR/EDR
- TX Power: +8 dBm with Bluetooth LE
- RX Sensitivity: -96 dBm
- 200-400 meter LoS range
MCU Features:
- ARM Cortex-M0
- 48 MHz
- 16 kB RAM
- 128 kB flash
Software Features:
- Integrated Bluetooth Smart Ready Stack
- BGAPI™ serial protocol API over UART for modem usage
- BGLIB™ host API which implements BGAPI protocol
- BGScript scripting language for standalone usage
- Profile Toolkit™ for creating GATT based services
Qualifications:
- Temperature range: -40° C to +85°C
- Bluetooth
- CE
- FCC
- IC
- Japan
- South Korea
