TouchXpress Common Specs
- Capacitive sensing input engine with up to 13 inputs
- Post-sample touch qualification engine
- Configuration profile space in non-volatile memory
- Pin output with configuration polarity and drive strength
- Low power state machine to minimize current draw in all use cases
- Capacitive proximity sensing input
- Buzzer output
- Mutually exclusive touch qualifier
- Touch time-out timer
- IEC60730 Class B compliance
Find the Right TouchXpress Device
Select Columns
| Part Number | Channels | Interface | Slider | Wake on Proximity | LED/Buzzer | Package Type | Package Size (mm) |
|---|---|---|---|---|---|---|---|
| 7 | GPIO Map | QFN20 | 3x3 | ||||
| 7 | GPIO Map | QSOP24 | 8.65x3.9 | ||||
| 12 | I2C | QFN20 | 3x3 | ||||
| 12 | I2C | QSOP24 | 8.65x3.9 | ||||
| 12 | I2C | QFN20 | 3x3 | ||||
|
|
13 | I2C | QFN24 | 4x4 |
